• Series GoBoard Live - MR6DE-E
• Screen Size 65" | 75" | 86"
• Colour Black & Tarnish

Display Panel

• Resolution 3840 x 2160
• Backlight Type Direct LED
• Colour Depth 10 bit (1.07B)
• Max. White Brightness 350cd/m²
• Native Contrast Ratio 65”, 75" - 1200:1 86" - 4000:1
• Viewing Angle 178°
• Colour Gamut (X% NTSC) 72%
• Refresh Rate 60Hz
• Life Time 50,000hrs
• Response Time 8ms

System

• CPU Architecture - ARM A73(4) + A53(4), Working Frequency - 2.2GHz + 2.0GHz
• GPU MaliG52

• RAM 4GB

• ROM 64GB

• OS Android 13.0


Touch

• Sensing Type Infrared Touch Frame
• Surface Protection Anti-Glare Glass
• Infrared Touch ≤ 20 points
• Touch Accurancy 90% (± 1mm)

• Theory Clicks Unlimited

• Min. Touch Object ≥ 2mm

• Multi Touch Windows 10/8/7, Android


Power

• Audio Output Power 2 x 15W + 20W
• Power Requirements AC 100V ~ 240V, 50/60 Hz
• Max. Power Consumption W/O OPS:

• 65” - 240W
• 75” - 350W

• 86” - 430W


Connectivity

• OPS Power DC 12V/5A Wi-Fi
• IEEE 802.11a/b/g/n/ac/ax (2.4G & 5G)

• IEEE 802.11a/b/g/n/ac (2.4G & 5G)

• Bluetooth BT 5.1

• NFC Yes

• Camera Yes


Input

• HDMI 2.0 IN x 3
• OPS (Optional) x 1

• LAN x 1 (1000baseT R)

• USB 3.0 x 3

• Type-C x 1 (Support PD 65W)

• Touch x 1

• Audio In x 1

• RS-232 In x 1 (RJ45)


Output

• RS232 Out x 1 (RJ45)
• HDMI Out x 1

• S/PDIF Out x 1

• Audio Out x 1


Dimension

Product Size (W x H x D)

• 65" - 1488 x 935 x 122 mm / 35 kg
• 75" - 1710 x 1060 x 126 mm / 45.8 kg

• 86" - 1955 x 1198 x 126 mm / 58.5 kg


Package Size (W x H x D)

• 65" - 1629 x 1040 x 240 mm / 45 kg
• 75" - 1850 x 1165 x 240 mm / 60 kg

• 86" - 2095 x 1303 x 240 mm / 74.5 kg


VESA (W x D)

• 65" - 600 x 400 mm
• 75" - 600 x 600 mm

• 86" - 1000 x 600 mm

• Wall Mount Screw M8/4
