• 4 10/100/1000 Mbps PoE ports
• 1 10/100/1000 Mbps Uplink port
• 60W PoE budget
• Supports IEEE 802.3af/at PoE to Power PoE capable network devices
• Supports transmission distance up to 250M
• Lightning protection 6KV
• Smart Features: Extend, VLAN, and PoE
• Plug & Play Installation

Size

• Desktop

Interfaces

• 4 10/100/1000 BASE-T ports
• 1 10/100/1000 BASE-T Uplink port

Standards

• IEEE 802.3 10BASE-T Ethernet (twisted-pair copper)
• IEEE 802.3u 100BASE-TX Fast Ethernet (twisted-pair copper)
• ANSI/IEEE 802.3 NWay auto-negotiation
• IEEE 802.3x ow control

Media Interface Exchange

• Auto MDI/MDI-X adjustment on all ports

Lighting Protection

• 6KV

Switching Fabric

• 10 Gbps

Transmission Method

• Adopt Store-and-forward

Data Transfer Rates

• Fast Ethernet
• 100 Mbps
• Gigabit Ethernet
• 1000 Mbps

Packet Filtering / Forwarding Rates

• 10M port maximum 14800pps
• 100M port maximum 148800pps
• 1000M port maximum 1488000pps

PoE Standards

• IEEE 802.3af
• IEEE 802.3at

PoE-Capable Ports • Ports 1 to 4
Power Budget • 60 W (30 W max. per PoE port)
Power • ✓
Link/Activity • ✓
Weight • 1 kg
Dimensions • 190 x 131 x 40 mm
Power • Internal power PSU: 60W
Temperature • Operating: 0 to 40 ˚C (32 to 104 ˚F)

Humidity

• Operating: 0% to 95% RH non-condensing
• Storage: 0% to 95% RH non-condensing

EMI/EMC

• CE
• FCC
