| Product Name | |
|---|---|
| Picture Performance | |
| Panel and backlit | DLED |
| Screen Surface Treatment | AG tempered glass Mohs level 7 |
| Contrast – typical | 65”: 1200:1 |
| Viewing angle (h/v) - typical | 178o |
| Color performance | 1.07 Billion Colors |
| Brightness – typical | 350 cd/m2(Typ) |
| Size and Resolution | |
| Aspect ratio | 16:9 |
| Resolution (native) | 3840(H) x 2160(V) |
| Picture Size (H x V) | 65”: 1428.48mm×803.52mm
|
| Pixel Pitch | 65”: 0.372mm |
| Response Time | 8ms(Typ) |
| Refreshing Frequency | 60Hz |
| Connectivity | |
| VGA/D-SUB | 1 x D-SUB |
| DVI | N/A |
| DP | N/A |
| HDMI | 1 × HDMI OUT, 3 × HDMI IN (HDMI2.0) |
| USB | 3 x USB 2.0 (including 2 USB ports in front) |
| 3 x USB 3.0 | |
| Audio In | 1 x 3.5 mm stereo phone jack |
| Audio output | 1 × Audio out |
| Built-in Speaker | Yes, 2 × 12 W |
| RS232 Control | 1 x RS232 |
| LAN | 1 × GIGABIT LAN (RJ45) |
| Touch System | |
| Sensing Type | Infrared recognition |
| Touch point | 10 points writing and 20 points touch |
| Writing Response | single-touch ≥6mm and multi-touch ≥8mm |
| Touch Tool | Finger, Finger cover by glove, Opaque objects |
| Response Time | <10ms |
| Accuracy | ±1.5mm(over 90% Area) |
| Communication Mode | Full-speed USB (driver free) |
| Surface Hardness | Toughened Glass with Level 7 of Mohs Standard |
| Wireless Screen Mirroring | |
| Wireless Screen Mirroring | Supports |
| Self-Hotspot Screen Mirroring | Supports |
| Reversely control Windows / MacOS | Supports, client software required |
| AirPlay protocol | Supports |
| Chromecast protocol | Supports |
| Power consumption (Typical) | |
| Soft switch off | ≤0.5W |
| Overall Power(nominal power) | 65”: 350W |
| Electrical values | |
| Rated voltage range | 100 V – 240 V |
| Rated frequency range | 50 Hz – 60 Hz |
| Protection class | 1 |
| Quality and Reliability | |
| MTBF (demonstrated) | 30,000h |
| Dimensions / Weight / Environmental | |
| Key Location & Number | Front physical keys, 1 |
| Dimension (L x H x D) | 65”: 1489×897×86mm |
| Dimension(package) LxWxH | 65”: 1656×204×1050mm |
| Net Weight | 65”: 40.2kg |
| Gross Weight | 65”: 51.3kg |
| Thickness of machine and wall mount | 116mm(9060G) |
| Wall-hanging Screw Spec | M8×25mm |
| VESA | 65”: 600×400mm |
| Miscellaneous | |
| Color | Black |
| Accessories | |
| AC Power Cable | British Standard Power Cord (3 meters), EU Power Cord (3 meters) |
| USB Cable | 5 meters |
| VGA Cable | 5 meters |
| HDMI Cable | 3 meters |
| Audio Cable | 5 meters |
| Writing Pen | 2 |
| Remote Control | 1 |
| Operation Instruction | 1 |
